PR25P-DV
Automatic, low maintenance, hot
melt edge pre-gluer, for pre-gluing
materials such as: plastic or wood
laminate strips, layered strips, 0.4 to
3 mm PVC, ABS, polyester, melami-
ne or wood veneer tapes. Like the
PR25P, it automatically glues tapes
for later use with edgebanders for
pre-gluedtapes,asmanufacturedby
Virutex,orwithanyhotairedgeban-
dingmachines. It has thermoelectric
temperature control, automatic
start and stop of the feed motor,
dependingon the glue temperature,
and an accurate dosage mechanism
whichdispensestheexactamountof
glue to obtain the required density
on the back of the tape. It has a
built-in, automatic winder which
easily unwinds rewinds it already
glued with no risk of accidental
gluing, thanks to the built in drying
unit. It has a lowmaintenance, non-
stick silicon dispenser roller which
prevents glue blockages.
Easy access glue tank on top. The
glue application system includes an
easy, non-stick silicon roller.
High quality pre-gluing.
Pre-gluing strips.
| Automatic hot melt pre-gluer
Standard equipment
Automatic winder, 2 multidiameter
reel centering devices, 1 kg of glue
and a cardboard roll centre ring.
Optionally, the machine can be fit-
ted with a triple winder (2545633)
for pre-gluing up to three edges at
the same time (edgeswith the same
thickness).Thistriplesthemachine's
production capacity, that is very
important for users who wish to
create a stock of pre-glued edges.
(contains: 4 reel loadingdiscs, 4 reel
centering discs, assembly booklet
and instructions).
Specifications
Input power
1720 + 120 W
Minimum tape thickness
0.4 mm
Max. tape thickness: strip/roll/roll+support 2545632
16/2/3 mm
Maximum tape width
104 mm
Feeding speed
510 m/h=8.5 m/min
Tape pre-glued with 1 Kg of glue
250 m of tape 25 mm width
Tank capacity
2 kg of glue
Weight
37.8 kg
2502522 Multi-diameter reel centring device (2
units included with standard equipment)
2545659 Pack of 25 Ø 85-mm cardboard rings
for edge roll centres
2545660 Pack of 25 Ø 150-mm cardboard rings
for edge roll centres
2599242 Hot melt glue, 1 kg bag
B
C
C
Optional accessories
A
A
2545632 Support for large
rolls. Ideal for 2 and 3-mm
thick edge rolls.
Optional
Pre-gluer for tapes
