NEW
Simply display screen. Glue temperature ad-
justment controlled bymicroprocessor, which
avoids the temperature oscillation.
Motorised pressure (gluing) roller. Optimum
capacity of the glue pot. Easy to reload and
to maintain clean thanks to its Teflon® cover.
Trimmingunitwithdigitaladjustment.Possibi-
litytotrimwithdifferentradiusor10ºchamfer.
Excellent finishings without adhesive residue
due to thedouble flat scraper. Automatic front
and rear flush cutting.
Easy to reload thanks to the special chute.
It's equipped with dispenser to reload the
glue while working, with no need to stop
the machine.
Simple and fast tape thickness adjustment. It
allows tapes up to 3 mm thick.
Precise control of the glue dosage on the
tape, which helps to adapt correctly the
performance of the machine to different
kind of materials.
Fast and easy adjustment. Perfect performance.
Minimum maintenance.
Standard equipment
Belt feeder unit
Motorised top andbottomtrimmingunitwith
TCT bits r=2 + 10º chamfer
Flat scrapers at both sides of the panel
Front and rear flush cutting
Table extension
Bits included as standard equipment
8540183 Upper bit Ø60 Z4, r:2, 10° bevel
8540184 Lower bit Ø60 Z4, r:2, 10° bevel
Optional bits
8540172 Upper bit Ø60 Z4, r:3, 10° bevel
8540173 Lower bit Ø60 Z4, r:3, 10° bevel
8540185 Upper bit Ø60 Z4, 45° bevel
8540186 Lower bit Ø60 Z4, 45° bevel
Optional accessories
8200300AS382LDustcollector,equippedwith
two motors and prepared to work during the
trimming cicles automatically.
8545498 Attachment with connectors Ø ext.
38-100mmFor general dust collection systems
with a minimum capacity of 1000 m
3
/h.
6399082 Cantspray. Silicone free anti-
adhesive spray.
8599694 Netspray. Multi-purpose cleaner.
2599266 Container of glue 4 Kg
Input power
3,450 W
Min. panel thickness
13 mm
Max. panel thickness (for tapes from 0.4 to 2 mm)
50 mm
Max. panel thickness (for 3 mm tape)
25 mm
Min. panel width
102 mm
Min. panel length
180 mm
Adjustable working temperature.
110°-200°C
Working speed
4 m/min
Trimming unit no-load speed
10,000/min
Trimming bits
Ø 59, Z4, R2, +10°
Voltage (single phase)
220-240 V
Dimensions
1,720x950x1,350 mm
Weight
150 kg
Specifications
