98
RC321S
1
2
3
RC221R
RC321S
doble
| Manual end trimmer
Forcuttingtheexcessoftapeatboth
ends of panel. It provides a clean and
exact cut, avoiding to damage the
panel already banded. For cutting
tapes on PVC, melamine, polyester,
veneer, etc... up to 45 mm width
and 2 mm thick. The blades can be
sharpened. Possibility to regulate
the cutting position.
Clean and exact cut.
Spare blades
2131101 Blade RC221R
Specifications
Max. tape width
45 mm
Max. cutting width with 1.5 mm tapes
45 mm
Max. cutting width with 2 mm tapes
35 mm
For cutting the excess of PVC, me-
lamine, polyester, veneer, etc. tapes
up to 45 mm width and 3 mm thick
at both ends of panel. It provides
a clean and exact cut, avoiding to
damage the panel already banded.
The guillotine system allows to cut
the tape without effort. The blades
can be sharpened. Possibility to
regulate the cutting position. It
enables precise angular cutting
up to 60º.
| Hand end trimmer for 3 mm tapes
1. Front trimming on
one side.
2. Front trimming on
some or all the sides.
3. Trimming of the corner
with the FR156N trimmer
(see page 26).
Spare blades
5231097 Movable blade
5231099 Fixed blade
Specifications
Max. cutting width with 1 mm tapes
55 mm
Max. cutting width with 2 mm tapes
45 mm
Max. cutting width with 3 mm tapes
25 mm
Edgebanders | Accessories
Cuttingonbothsidesonstraight
panels.
Cutting system with two blades.
Cutting on circular panels.
NEW
