101
EB35
Edgebanders
Specially designed for banding
preglued PVC, polyester, melamine
and veneer tapes. Possibility to band
and trim tapes up to 3 mm thick.
Belt feeder for automaticworkpiece
feeding. Top and bottom trimming
by two independant motorized
trimming units, equipped with TCT
bits; possibility to trim with radius
or straight edges. Scrapper unit
and automatic tape feeding system.
Front and rear flush cutting of the
tape (for tapes up to 2 mm thick).
Minimum heat up time. Electronic
temperature control. Minimal, easy
maintenance. Large surface table
with special guides.
Automatic workpiece feeding.
Front and rear flush cutting (tapes
up to 2 mm thickness only).
Simultaneous top and bottom
trimming, with radius or 10°
chanfer. Flat scrappers after the
trimming unit.
Standard equipment
Belt feeder unit
Motorized top and bottom trim-
ming unit with TCT bits r=3+10°
chanfer
Scrapper unit
Front and rear flush cutting
Table extension
Single phase 220-240 V
No compressed air required.
Specifications
Input power
4,000 W
Min. panel thickness
13 mm
Max. panel thickness 1 mm tape
50 mm
Max. panel thickness 2 mm tape
35 mm
Max. panel thickness 3 mm tape
25 mm
Min. panel width
102 mm
Min. panel length
110 mm
To ensure the tape is well banded,
the EB35 incorporates two auxiliary
rollers on the banding table and a
special pressers set, allowing the
optimum pressure of the panel on
the banding unit. This ensures a co-
rrect banding, specially when using
thick and rigide tapes. The EB35 is
also equipped with a selection lever
to regulate the correct workpiece
position depending the tape thic-
kness. A heating unit «Leister» with
electronic regulation, from 0° to
500°, is ensuring a correct banding
temperature for any kind of tapes.
Electronic temp.control
0°-500°C
Working speed
4 m/min
Trimming unit no-load speed
10,000/min
TCT bits
Ø 59, Z4, R3, +10°
Voltage (single phase)
220-240 V
Dimensions
1,720x950x1,350 mm
Weight
135 kg
| Edgebander
Optional accesories
8200300 AS382L Dust collector,
equipped with two motors and pre-
pared to work during the trimming
cicles automatically
8545498 For general dust collection
systems with a minimum capacity
of 1000 m
3
/h. Attachment with
connectors Ø ext. 38-100 mm
6399082 Cantspray. Non-adherent
without silicone
8599694 Netspray. Multi-purpose
cleaner
PR25P Pregluers (see page 113-114)
Optional bits
Carbide bit r=3+10° (included as
standard equipment)
Carbide bit r=2+10°
Carbide bit 45°
