96
AG98R
Edgebanders
| Manual edgebander
Specifications
Input power
1,500 W
Maximum banding width (1 mm thickness)
50 mm
Maximum banding width (3 mm thickness)
25 mm (pre-cut strip)
Temperature
I: 300°C II: 525°C
Air delivery
400 l/min
Weight
2.8 kg
For banding preglued PVC, polyes-
ter, melamine and veneer tapes.
Enables to band circular or shaped
pieces. Its special design with adjus-
table clamps ensures high precission
work with great stability.
Practical end trimming system
included. Possibility to band flush
with panel surface or with excess
on either of both sides. Set up time
less than one minute.
Two tape feeding systems:
Holder for tape rolls up to 1 mm
thickness and 50 mm width.
Manual feeding for pre-cut strips
up to 3 mm thickness and 25 mm
width.
It also includes as standard a roll
holder for banding with rolls.
Optional accessories
2800000 AU93 Edge trimmer
2100000 RC21E End trimmer
5600300 FR156N Trimmer
2100600 RC221R End trimmer
5246025 Roller inclined at 4° for
edge-banding on inclined door
surfaces, etc.
Clamping systems (see page 89-92)
Easy to place the pre-cut strip.
High precission and stability during
edgebanding.
Manual feeding for banding pre-cut strips up to 3 mm thickness and 25
mm width with high precission and stability.
Possibility to band straight, circu-
lar or shaped pieces.
4 possibilities
