102
EB140
Hot melt edgebanders
Machin eequipped with a PCL
controller.
Automatic hot melt edgebander for
standardtapesupto3mmthickness.
The EB140 allows a high quality
edgebanding. The adjustment is very
easy thanks to its digital meters.
The accessibility to the machine
parts is fast and comfortable. The
machine is equipped with doors
and movable elements which make
easy all the possible adjustments.
Direct adjustment of the trimming
bits and copiers. Simultaneous
adjustment for the tape thickness,
intake guide and gluing roller by a
single digital meter.
Motorised pressure gluing roller.
Allows a perfect banding from the
beginning of the panel (patented
system).
Automatic pneumatic end trimmer
for tapes up to 3 mm thickness. No
adjustment is required.
Trimming unit at 10000/min equip-
ped with adjustable copiers.
Panel thickness adjustment by
digital meter.
Powerful panel feeder
with wide belt. Optimal
feeding of pieces more
than 2 m long.
Trimming unit at
10000/min equipped
with adjustable copiers.
Telescopic frontal extension
with rollers.
Panel thickness ad-
justment by digital
meter.
Working table equip-
ped with antifriction
material and rubber
pressure rollers.
| Automatic hot melt edgebander
Video
Gluing roller with polymerization
processing.
Reduces the consump-
tion of glue. Allows to band ABS
tapes with 3D and glass effect with
the optional roller ref. 8504319.
Automatic pneumatic
end trimmer for tapes
up to 3 mm thickness. No
adjustment is required
