100
EB25
For panel edgebanding with pre-
glued PVC, melamine and veneer.
Automatic edge feeding system.
Trimming on both sides. Motorized
topandbottomtrimmingunit.Front
edge trimming, rear flush cutting of
the tape. No compressed air or dust
collector required. Powerful hot air
systemwith electronic temperature
control. Minimum heat up time (2
min). Belt feeder for automatic
workpiece.
Safety control (STOP). Electronic
temperature control.
Standard equipment
Motorized trimming unit
Belt feeder
Table extension
End cutting of front and back
of the tape.
Specifications
Input power
3,000 W
Min. panel thickness
11 mm
Max. panel thickness
50 mm
Electronic temp. control
0°-500°C
Working speed
4.2 m/min
Dimensions
1,720x950x1.350 mm
Weight
117 kg
CantSpray is a non-adherent silicone free spray for all movable parts of
the edgebanding machines (trimming bits & end cutting blades). It helps to
keep clean all the elements from the adhesive residue, which ensures the
perfect final performance of the machine. It's silicone-free, so it doesn't
leave grease marks on the used materials and doesn't interfere with af-
terwards treatments (painting, lacquering, varnishing, etc).
NetSpray is a multi-purpose cleaner for effortless removal of adhesive
residue, glue streaks and other impurities on all kind of plastic surfaces
(like PVC, melamine, ABS, etc). Dries quickly without leaving streaks. It's
presented in spray and possesses a pleasant citrus aroma.
Optional accessories
PR25P Pre-gluer for tapes
(see page 113-114)
6399082 Cantspray
8599694 Netspray.
Power trimming unit: trimming
both sides simultaneously.
Feedunit: feedingof theworkpiece
to be edged.
Edgebanders
| Edgebander
Single phase 220-240 V
No compressed air required.
Cantspray and Netspray
