CO49K
Laminate cutters
The CO49K automatic slitter is the
result of the experience of Virutex
asmanufacturer of laminate cutting
machines. It allows to cut strips from
laminate, plastic, veneer and other
light non metallic materials. Its fe-
eding system, bymean of motorized
rubber rollers and the exclusive
cutting system by wheel blades,
allows clean splinter free cuts. It
is possible to work with laminate
sheets of any dimensions, thanks
to its well dimensioned table giving
a good stability for having perfect
cuts. No additional work is required.
Equippedwithwheelspacers,special
for laminates. It is also equipped
with a movable cutting guide and
a scale for an easy adjustment of
the cutting wide.
Easy to regulate, easy to mantain.
Easyadjustmentofthecuttingwide.
Specifications
Input power
180 W
Feeding speed
13.6 m/min
Max. cutting thickness
1.6 mm
Minimum cutting length
185 mm
Regulable cutting width
16-635 mm
Weight
44 kg
Optional accessories
5800100 MT58K movable
working table
Blades
1527075 Set of 2 wheel blades
It is possible to work with laminate sheets of any
dimensions, thanks to its well dimensioned table
giving a good stability for having perfect cuts.
| Automatic slitter
