79
0° - 0°
160
95
0° - 45°
110
45°
95
45° - 0°
160
45°
64
45° - 45°
45°
45°
64
75
TM233W
TS233W
0° - 0°
0° - 45°
45° - 0°
45° - 45°
| Mitre saw
Highprecisionportabletiltablemitresaw.Bigcutting
capacity, tilting head from 0° to 45°. Equipped with
carbide saw blade 96 Z for aluminium and pressers
set. Integral safety system with saw blade brake
and protection against intempestive switch on.
Connection for external dust collection.
Includes shut-off button for easy change of saw
disc. No noise from gears: belt transmission with
safety tension.
Optional accessories
3345470 Set of lateral handles
3346388 Set of supp. cut 200 mm
5800100 MT58K Portable table
Specifications
Input power
1,500 W
No-load speed
3,700/min
Saw blade diameter
300 mm
Weight
19 kg
Profile cutting capacity
disc-head
45x200mmwith36mm supplement
Saw blades
see page 81
Mitre saw
Highprecisionportable tiltablemitre saw. Big cutting
capacity, tilting head from 0° to 45°. Equipped with
upper table, carbide saw blade 72 Z for aluminium
andpressers set. Integral safety systemwith sawblade
brake and protection against intempestive switch on.
Connection for external dust collection.
Includes shut-off button for easy change of saw
disc. No noise from gears: belt transmission with
safety tension.
Specifications
Input power
1,500 W
No-load speed
3,700/min
Saw blade diameter
300 mm
Weight
19 kg
Optional accessories
3345470 Set of lateral handles, 3346388 Set of supp. cut 200 mm,
6446073 Standard dust collector attach. 2.25 m (for upper table),
5800100 MT58K Portable table, 7246098 Square for table.
| Mitre saw
Cutting capacity
(disc-head)
Max. cutting capacity on upper table
: 50 mm
45x200mmwith36mm supplement
Saw blades
see page 81
Aluminium + PVC + Wood
Aluminium + PVC
