UCP90
Accessories for saws
B
| Cutting guide
The UCP90 guide allows to make
straightcuts,givingaperfectguiding
of the saw with total stability. It is
adaptable to all the Virutex models
of circular and jig saws.
Equipped from factory with two fi-
xing systems, allowing a safe holding
on the piece to work: two suction
pads, for smooth and non-porous
surfaces and a set of two clamp
screws to be fixed on the lower
side of the guide, even if the guide
is longer than the panel.
The guide is also provided with non-
slip strips to protect the panel from
possible scratches.
Non-slip strips for a better fixing.
They protect the panel frompossible
scratches.
Two clamp screws included for fixing
the guide from the lower guide.
The guide can be fixed by means of
the two suction pads included (on
smooth and non-porous surfaces).
Standard equipment
Guide 1400 mm long with
adaptor for SR90J circular saw,
2 suction pads and 2 clamp
screws.
Optional accessories
9045767 Adaptor for SR74K
9045754 Guide 1400 mm length.
9045755 Guide 2400 mm length
6045756 Set of 2 suction pads UCP90
6045710 Set of 2 clamp screws
9045812 Jointing kit for UCP90 guide
B
C
A
A
The SR90J circular saw can be mounted on the cutting
guide directly (adaptor not necessary).
C
D
The SR74K circular saw can be mounted on the cutting
guide by means of the optional support ref. 9045767.
A
Circular saws + UCP90
