68
RZ270S
Specially designed for cutting doors,
door frames, base boards and skirtings,
it is ideal for installers of parquet or
such other floor coverings as carpets,
ceramic tiles, etc. Equipped with a
powerful motor it provides a clean
and precise cut easily and quickly. The
cutting height and depth are adjusta-
ble by means of its milimetric gauges.
Its cutting depth allows to cut the
doors at once.
Includes dust collection nozzle and
pipe for connection to an external
dust collector.
Optional saw blades
7040193 Diamond disc (Ø 150), for
cutting bricks, concrete, granite,
ceramics and stoneware
7040316 Saw blade for cutting
metals (Ø 165, Z 30), ideal to cut the
metal sheets on the armored dors
It cuts door frames without to di-
sassemble the butt straps, providing
a precise and clean cut.
Its cutting depth allows it to cut the
doors at once without splintering.
High fiability when cutting base-
boards or skirtings.
Machines for parquet industry
Specifications
Input power
1,300 W
Cutting depth
0-47 mm
Minimum cutting height
8 mm
Maximum cutting height
35 mm
No-load speed
5,000/min
Weight
5.6 kg
Standard equipment
Carbide saw blade Z 24 Ø 165 mm
for cutting doors and skirtings (ref.
7040314), dust collection pipe 2.25
m long, carrying case and service
keys.
| Trimming machine
Thanks to the possibility to
take away the front part
of the head it is possible to
arrive to the corner when
cutting the skirtings.
Cutting a shadow joint.
Video
