RV70U
Installation and restoration of doors and windows
The new RV70U trimmer is designed
to cut wooden window frames and
for use in restoration work or window
replacement by creating slots around
the frame, making it easier to extract
the frame support.
For window frame cutting, the RV70U is
equipped with a special saw blade of 12
hardmetalteethandanadjustablefront
square guide which is used as a support
guide for the cut. To create slots in the
frame support structure, theRV70Ualso
comeswithadiamondbladedesignedto
cut buildingmaterials. It can evenmake
slots in the four corners; to do this the
user simply has to change the position
of the machine’s reversible base to the
bevelled side.
The new RV70U makes the task of
replacing windows much easier while
retaining the original size or even
increasing it in some cases. It is also
an indispensable tool for installing
aluminium or wooden windows.
| Window frame cutting machine
Trimming wooden window frames.
Register on the adjustable front
guide square.
Makes cutting slots in the 4 cor-
ners easy.
Register on the bevelled front of
the reversible base.
Specifications
Input power
1,700 W
No-load speed
6,500/min
Max. cutting depth with saw blade
68 mm
Max. cutting depth diamond blade
58 mm
Height of the cut from the base
7 mm
Weight
6.6 kg
Standard equipment
Front square guide to trim windows,
12Z MD D.200 blade to cut wood,
D.180 diamond blade to cut building
materials, 3-m dust collection tube and
carrying case.
Diamond blade for cutting building
materials for the complete extrac-
tion of the frame. Register on the
straight front of the reversible base.
Optional accessories
9545854 Kit GRM70S: includes the guide and the accessories
needed to turn the RV70U into a door frame trimmer.
7040330 Saw blade D.200 30 Z
Carbide saw blade for wood
12Z Ø 200 (ref. 7040371) and
diamond blade Ø 180 (ref.
7040329) for building materials
as standard equipment.
