61
Specifications
Input power
1,000 W
No-load speed
14,000 - 27,000/min
Chuck collet
8 mm
Max. bit diameter
32 mm
Max. trimming dim.
165 x 74 mm
Max. trimming depth
11 mm
Guide rings
2950104 Ø ext. 10 mm (for 6 mm bits)
2950105 Ø ext. 12 mm (for 8 mm bits)
2950106 Ø ext. 14 mm (for 10 mm bits)
2950107 Ø ext. 16 mm (for 12 mm bits)
2950081 Ø ext. 18 mm (for 14 mm bits)
2950108 Ø ext. 20 mm (for 16 mm bits)
Optional accessories
Templates for fitting
different types of hinges
2935142 Special eyebolt templates
Max. trimming depth (with kit for concealed hinges)
40 mm
Max. clamp opening*
200 mm
Min. clamp opening
33 mm
Weight
4.3 kg
To make other recesses both on frames and doors it is
not necessary to readjust the machine.
This accessory allows to cut
the radiuses left by the bit on
the corners of the trimmed
recesses for hinges, giving
an exact 90º corner. It is very
useful when fitting hinges
with square corners.
Solid and ergonomic design
protects the user from the
cutting blades.
Optional accessories
RC29M Corner chisel (optional)
Kits for fitting concealed hinges
2946765 kit for fitting concealed hinges
with carbide bit Ø14 mm
2946768 kit for fitting concealed hinges
with carbide bit Ø15 mm
2946767 kit for fitting concealed hinges
with carbide bit Ø16 mm
2946766 kit for fitting concealed hinges
with carbide bit Ø20 mm
Bits
1640383 Carbide bit Ø14 mm
1640379 Carbide bit Ø15 mm
1640127 Carbide bit Ø16 mm
1640367 Carbide bit Ø20 mm
(*) Also available with max. opening clamp up to 250 mm.
