P
Carbide bit for rims
Carbide bit for rims
Carbide trimming bit w/upper bearing
Ref.
EAN13
D d L
R TL
Rpm max.
1740322
8421752077614 10 12 13 5 69
20000
1740324
8421752075801 20 12 14 10 65
18000
Ref.
EAN13
D d L
R TL
Rpm max.
1740362
8421752078369 20 12 14 10 65
18000
1740363
8421752078376 10 12 13 5 69
20000
Ref.
EAN13
D d
L
TL
Rpm max.
1740347
8421752077461 24
12 25 84
N O M E N C L AT U R E
Trimming carbide bit 45ºx26
Fraise à chanfreiner 15° avec GAB conique
Ref.
EAN13
D d L
TL
Rpm max.
1740349
8421752077485 50 12 26 45° 80
20000
Ref.
EAN13
D d L
TL
Rpm max.
1740341
8421752077409 33,5 12 25 15° 75
2 cuts carbide straight bit
Ref.
EAN13
D d
L
TL
Rpm max.
1140257
8421752065000 10
12 32 73
1140258
8421752065017 12
12 32 73
2 cuts helicoidal full carbide bit
Ref.
EAN13
D d
L
TL
Rpm max.
1740332
8421752077317 10
10 35 73
1740333
8421752077324 12
12 45 84
D: Max. cutting diameter
d: Collet diameter or diameter as showed on
the picture.
L: Cutting length
R: Main radius
r: Radius as showed on the picture
a°: Angle
TL: Total length
Rpm máx.: Max. speed x min
-1
Bits for Corian
®
and other solid surface materials
