Jointing machine
Joints in middle of board.
Mitre joints.
Square joints.
Types of joints
Stronger joints with No. 6 splines.
Specially designed for joints. They work like dowels or blocks but
with greater advantage.
The joint is assured thanks to the resistance of the wooden splines
which are more resistant than dowels or blocks.
Ref.
Model
Specifications
Box
1405001 No. "0"
47x15x4 mm. Slot depth 8 mm
1000 un.
1405002 No. "10" 53x19x4 mm. Slot depth 10 mm
1000 un.
1405003 No. "20" 56x23x4 mm. Slot depth 12 mm
1000 un.
1405004 No. "6" 85x30x4 mm. Slot depth 20 mm x2*
500 un.
(*) 2 contiguous slots at 15 mm
Assembly wooden splines
With the AB111N it is possible toperform multiple types of assembly, whether in the
middle of the board, a miter square or even frame assemblies.
Optional accessory
2546409 Hand gluing set SEM1
Contents:
Plastic bottle of 250 ml
Dispensers for splines and dowels
Gluing roller 60 mm width
Gluing brush
Caps for each element
