PFE60
Routers · Accessories for routers
Precise and solid template manu-
factured in phenolic material 12
mm thick. Specially designed for
trimming and assembling work tops
from 420 mm to 650 mmwidth. The
assembling angle canbe 45º or 90º. It
is also possible to trimm radiuses for
makingtheexternalroundtrimming.
It is ideal to use with the routers
modelFR160P.Veryeasytoplaceand
fix following the marked references
on the template. Reduced trimming
time, just about 15 minutes for the
two sides of a work top.
| Template for trimming work tops
Specifications
Minimum work top width
420 mm
Maximum work top width
650 mm
Assembling angle
45° or 90°
Standard equipment
Template for trimming work
tops, 3 steel stoppers and adjus-
table stopper.
Optional accesories
6045699 Suction pad for fixing the template (2 pcs. needed)
6045710 Set of 2 jointing screws
7722114 Guide ring, external dia. 30 mm., h=10 mm
1640258 Bit Ø 12 mm L35 Z3 for 12 mm collet
6040310 Bit Ø 12 mm L32 Z2 for 8 mm collet
6045711 Set of 10 jointing screws
Cross form trimming for jointing
both sides of work top.
Adjustablestopperforacorrectposi-
tioning. It allows to correct the angle
between the wall and the work top.
Steel stoppers.
Minimum trimming time, just in
about 15 minutes the trimming on
both sides of the work top is made.
The assembling angle can
be 45º or 90º.
