AB111N
Jointing machine
Specifications
Input power
800 W
Blade
100x22x4 mm
No-load speed
10,000/min
Max. slotting depth
20 mm
Weight
2.6 kg
Angle and height of the front fence
can be adjusted on a graded scale.
Quick adjustment of different slot-
ting depths.
Standard equipment
Carbide blade 100 x 22 x 4, of 2
teeth and 2+2 spurs, carrying case,
external dust collection connector.
Lateral fence CB64B
Cutting back skirting board for
placing parquet.
Repairing head CA64B
Optional accessory for the repair
of damaged wood (small pockets
of resin, knots, etc), blade not
included.
| Jointing machine
The jointing machine AB111N is
specially designed for slotting panels
in any position. Thanks to the design
ofitsmicrometricfence,whichcanve
adjustedatanyheightandangle,and
to a graphic signs it is not neccessary
totakeexactmeasurements,duethat
it is possible a lateral deplacement
of 2 cm for adjusting the joint once
made the slot. A preadjusted stopper
allows to select the different slotting
depths fast and easy. Equipped with
electronic control system which
maintains the speed constant in-
dependently to the working load,
allowing to make the slots in a easy
and precise way in all kind of woods.
Optional accessories
6446073 Standard dust collector attachment 2.25 m
2546409 Gluing set SEM1
Frontal fence with non slide rub-
ber stoppers for a better machine
stability.
Bit for CA64B
Bit for repairing resin pockets
on wood. (ref. 6440376)
