PL11
Routers · Accessories for routers
Start of dowel canbe adjusted from
both sides. High precision joints.
4 types of dovetail joints. Perfect
finish on dovetail joints.
Precission attachment for dovetail
jointing. Equipped from factory
with a dovetail template pitch 26
mm. Possibility to use other pitch
dimensions with the additional kits.
Fine adjustment of the dovetail
beginning. Perfect dovetail joints.
Can be usedwith our routers models
FR66P, FR160P, FRE160P, FR277R,
FR278R and the trimmer AS93 with
the CA66F routing head.
Can be secured to the workbench.
As the machine is fully supported by
the dovetailing attachment you can
work with total stability, with no risk of
damaging joints.
Specifications
Working width
360 mm
Pitch plate
26 mm
Optional pitch plates
16 or 34 mm
Minimum workpiece thickness
10 mm
Maximum workpiece thickness
30 mm
Weight
6.2 kg
Optional accessories
6045710 Set of two clamp screws
7745149 Dovetailing kit pitch
plate 16 mm
7745150 Dovetailing kit pitch
plate 34 mm
6040050 Dovetailing bit Ø 15 mm
1140060 Straight bit Ø 12 mm
Standard equipment
Template pitch plate 26 mm
| Dovetailing attachment
