28
AS93
Trimmers
Trimmer for laminate shaping. Its
powerful 1,100 W motor makes it
specially suited for heavy work. It
can be easily converted into a sur-
face router with the routing head
CA66F for working with the PL11
template for dovetail joints or other
routing works.
Trimming laminates.
Making mouldings.
Optional accessories
6027056 Chuck collet 8 mm
6727020 Chuck collet 6.35 mm
(1/4”)
6600050 CA66F Routing head
6650088 CPN66 Hinge fitting
head
Clamping systems (see page 89)
Templates for fitting hinges
(see page 62)
FittinghingeswiththeCPN66head.
Guides rings
To be used with CA66F routing head
7722168 Ø ext. 10 mm (for 6 mm bits)
7722120 Ø ext. 12 mm (for 8 mm bits)
7722121 Ø ext. 14 mm (for 10 mm bits)
7722122 Ø ext. 16 mm (for 12 mm bits)
7722169 Ø ext. 18 mm (for 14 mm bits)
7722118 Ø ext. 20 mm (for 16 mm bits)
7722119 Ø ext. 27 mm (for 23 mm bits)
7722114 Ø ext. 30 mm (for 26 mm bits)
7722123 Guide for PL11 width 26 mm
7722161 Guide for PL11 width 16 mm
7722162 Guide for PL11 width 34 mm
7722160 Guide for AGB template
6640125 Bit for AGB template for bottom-
hung fittings
Standard equipment
Flush/bevel carbide bit and
service keys.
Routing head CA66F (optional) to
transform the AS93 into a router.
Specifications
Input power
1,100 W
Chuck collet
6 mm
No-load speed
23,000/min
Weight
3.7 kg
| Trimmer
Bits
see pag. 48
