FR256N
This set includes the FR156N edge
trimmer and the CA56U trimming
head which allows to trimm al the
edges of the panel continuosly. The
CA56U trimming head has a large
support surface and an auxiliary
knob. Idela for a trimming work on
the panel edge.
Optional accessoires
1222084 Chuck collet 6 mm
1222085 Chuck collet 6.35 mm (1/4”)
6446073 Standard dust collector attachment 2.25 m
1746245 Standard dust collector attachment 5 m
1140106 HM bit r=3 mm with bearing
1140109 HM bit r=6 mm with bearing
1140110 HM bit r=8 mm with bearing
6399082 Cantspray
Specifications
Input power
750 W
No-load speed
14,000-30,000/min
Chuck collet
8 mm
Weight
1.6 kg
| Edge trimming set
Trimmers
Standard equipment
FR156N Edge trimmer (with stan-
dard head), carbide bit r=2mmwith
bearing(1140123),CA56Utrimming
head (5600060) and carrying case.
Veryeasytrimmingofeitherstraight
or shaped pieces.
Easy preparation for corner trim-
ming
Preciseguidingforcornertrimming.
Vacuum connection equipped with
a bearing brake to prevent leaving
marks on the edge.
The new fine adjustment system
makes it very easy to regulate
trimming head height.
Round head (V3) included with the
set.Verypracticalfortrimmingwith
support on edges and essential for
jobs that require this type of work.
The V3 head includes its own va-
cuum collector with a brake, and
is also supplied with three sliding
bases. (Holes d= 20, 26 and 30
mm).
Clamping systems (see page 89)
