PE60
Multiradius template for trimming
circular or elliptical forms. Ideal for
manufacturingmirrors,windows,doors
oranyotherdecorative itemsbymeans
of an elliptical or circular trimming.
The use of the two guide supports
(standard equipment) allows the
elliptical trimming and the use of only
onesupportallowsthecircularexternal
trimming or moulding.
The PE60 is also equipped with two
suction pads for fixing it to the pan-
nel to be trimmed. Thanks to them it
is possible to trimm in an easy way
without to perforate the surface. If
it is not posisble to use the suction
pads there are several holes to fix the
template by means of screws.
Includes two rod guides Ø 8 mm for
using with all the Virutex routers.
| Template for trimming ellipses and circles
Routers · Accessories for routers
Opening for
Opening for
Round corner
Extendable round
Oval table
Round table
rounded door
oval door
on a desk
or oval table
Fixation by suction pads (included)
or screws.
Ellipses, max. length of main axis: 3200 mm, min. length of minor axis:
600 mm (with a router).
Circle, max. diameter: 3200 mm, min. diameter 600 mm.
Standard equipment
Template for trimming ellipses and
circles, two suction pads, extenda-
ble guide and coupling system plus
rods Ø 8 mm for Virutex routers.
Optional accessories for PE60 & UC60
6045714 Special coupling rods for FR292R
6045708 Set of coupling rods Ø 10 mm
6045709 Set of coupling rods Ø 12 mm
6045710 Set of two clamp screws
UC60 Universal compass guide
For trimming circles between 400 and 3200 mm.
(ref. 6045715)
Includes: Support, suction pad,
adjustable holding rod and
coupling with Ø 8 mm rods for
fixing the router.
