29
FR277R
FR278R
Surfaceroutersforroutingwoodand
plastic. Ideal for deburring edges,
cutting out knots, copy routing,
trimming, constructing frames and
tooling, etc. Quick adjustment of
routingdepthwith3pre-established
positions. The model FR278R has a
powerful 1,300 W motor and elec-
tronic speed control. External dust
collection connector.
Routers
Specifications
Input power
1,010 W
Chuck collet
8 mm
No-load speed
24,000/min
Routing depth
0-50 mm
Weight
2.9 kg
Specifications
Input power
1,300 W
Chuck collet
8 mm
No-load speed
6,000-27,000/min
Routing depth
0-50 mm
Weight
3 kg
High precision and stability during
routing.
Quick adjustment of routing depth
with 3 positions.
Model FR278R with electronic
speed adjustment.
Lateral fence with micrometric
adjustment.
Optional accessories
(models FR277R & FR278R)
6446073 Standard dust collector attachment 2.25 m
1746245 Standard dust collector attachment 5 m
6045669 Compass guide
6045715 UC60 Universal compass guide
7722116 Reducer 6 mm
7722115 Reducer 6.35 mm (1/4”)
7722161 Guide PL11 width 16 mm
7722123 Guide PL11 width 26 mm
7722162 Guide PL11 width 34 mm
7722160 Guide for AGB template
7722342 Guide for AGB template
7740117 Bit for AGB template for bottom-hung fittings
Templates for fitting hinges (see page 62)
Clamping systems (see page 89)
9045705 UC90P Cutting guide
| Router
| Electronic router
Lever for blocking the routing
head, accesible from the handle.
Standard equipment
Lateral fence, dust collector connection and
service keys.
Guide rings
(
models FR277R & FR278R)
7722168 Ø ext. 10 mm for 6 mm bits
7722120 Ø ext. 12 mm for 8 mm bits
7722121 Ø ext. 14 mm for 10 mm bits
7722122 Ø ext. 16 mm for 12 mm bits
7722169 Ø ext. 18 mm for 14 mm bits
7722118 Ø ext. 20 mm for 16 mm bits
7722119 Ø ext. 27 mm for 23 mm bits
7722114 Ø ext. 30 mm for 26 mm bits
Bits
see pag. 48
