26
FR156N
Optional accessoires
1222084 Chuck collet 6 mm
1222085 Chuck collet 6.35 mm (1/4”)
5600060 CA56U Trimming head
6446073 Standard dust collector attachment 2.25 m
1746245 Standard dust collector attachment 5 m
1140123 Carbide bit r=2 mm w/ bearing
1140109 Carbide bit r=6 mm w/bearing
1140110 Carbide bit r=8 mm w/bearing
6399082 Cantspray
Easy touse and excellent finishings.
Perfect finishing in a
few time.
For trimming edges of PVC and
veneer. Equipped with a carbide bit
r=3 mm with bearing (1140106).
Optional bits are available for
several different radius. Powerful
motor (750 W) and electronic speed
adjustment. Also equipped with
electronic control maintaining the
speed constant, independently than
the working load. Dust collector
connection and three bases (hole Ø
20, 26 and 30 mm) for using with
bits of different diameters.
The CA56U trimming head enables
uninterrupted trimming of the four
edges of a panel. It has a large sup-
port base and an auxiliary holding
knob, designed to give it perfect
stability.
Specifications
Input power
750 W
No-load speed
14,000-30,000/min
Chuck collet
8 mm
Weight
1.6 kg
| Edge trimmer
Trimmers
It is possible to trim all sides of the
panels with radius or a chamfer.
High quality finishing on corners.
Special brake system for the ball
bearing of the bit, avoiding that
it can damage the panel when
starting to work.
The new fine adjustment system
makes it very easy to regulate the
trimming head height.
Clamping systems (see page 89)
