LR284R
LR84H/LRE84H
Optional accessories
8499211 Accesory for velcro
sanding papers
8445598 Velcro rotary orbital disc
8445232 Centering device
6446073 Standard dust collector
attachment 2.25 m
Sanders
Light and powerful miniorbital
sander for polishing and finishing.
Its ergonomic design makes it less
tiring to use and the controls more
easily accessible. Includes an extra
base with a delta shape for velcro
sanding sheets, making it ideal for
sanding difficult to reach surfaces
such as frames, blinds, etc. Integra-
teddustcollection.Canbeconverted
into a rotary orbital sander by using
the optional disc.
The LRE84H model has electronic
speed control, which allows you to
choose the most suitable speed to
the material.
Ideal for sanding and finishing
frames and other surfaces.
Sanding difficult to reach areas
such as blinds, etc...
Usingthedeltabaseinteriorcorners
are quick and easy to sand.
Specifications
Input power
180 W
Orbit diameter
2 mm
Pad size
80x130 mm
No-load speed
LR84H 12.500/min - LRE84H 7,000-12,500/min
Strokes
LR84H 25.000/min - LRE84H 14,000-25,000/min
Weight
1.5 kg
High quality finishing on several
kind of surfaces.
Specifications
Input power
180 W
Orbit diameter
2 mm
Pad size
93x185 mm
No-load speed
12,500/min
Strokes
25,000/min
Weight
1.5 kg
Light and powerful sander for
sanding any kind of surfaces. Its
ergonomic design allows a perfect
holdingandasmallerfatigue,thanks
toitsperfectbalancing,reducingthe
vibrations level for the user.
Equipped with a big long life po-
lyurethan sanding base allowing
to sand near the corners or edges
without damaging or scratching.
This feature avoids the metal parts
can be in contact with mouldings
or other elements.
The base dimension, 93x185 mm,
makes it ideal for sanding narrow
surfaces, between mouldings or
other elements on both sides.
Integrated dust collection.
Strong aluminium base.
Optional accessory (8499219) for
velcro sanding papers.
Optional accessories
8499219 Accesory for velcro
sanding papers
8445571 Centering device
6446073 Standard dust collector
connection 2.25 m
| Light orbital sander
| Miniorbital sanders
Sanding sheets
see pag. 23
Sanding sheets
see pag. 23
