7
CE24E
CE120P
Optionally it can be delivered
with carrying case.
Designed andmanufactured for he-
avyworkwith the highest standards
of quality. The single piece housing
is made entirely of aluminium. Pla-
ning base 455 mm lenght. The high
power rating of 1,200 W allows it
to perform the heaviest and most
demanding types of work.
Equipped with replaceable carbide
reversible blades and dust collector
connection.
Optional accessories
2250012 Planer stand for using the
planer in a stationary position
2200018 Micrometric fence for
making bevelles edges
Blades
3540118 Set of 2 carbide reversi-
ble blades
3531019 Set of 2 HSS reversible
blades
3599101 Reversible blades holder
It has been specially designed to be
highly ergonomic and therefore to
adapt easily to professional use. This
machine is comfortable to use and
well balanced, guaranteeing comfort
and precision. It is equally suited to
left-and right-handed use. Planing
base 316 mm lenght.
Equipped with blade-holder brake,
rest shoe, double regulation and
some other features similar tomodel
GR120P.
Provided with replaceable carbide
reversible blades and dust collector
connection.
Dust collector connection.
Adjustable lateral shoe for rabbe-
ting up to 25 mm.
Shavings-ejection selector lever
(right-left).
With carrying case.
Micrometric fence. For making
bevelled edges at different angles.
Optional accessories
2045381 Micrometric fence for
making bevelles edges
2000150 Planer stand for using
the planer in a stationary position
Blades
2031082 Set of 2 holders with 3
mm HSS reversible rustic blades
2031079 Set of 2 HSS reversible
rustic blades 3 mm
Specifications
Input power
750 W
Cutting width
82 mm
Cutting depth
0-4 mm
Rabbeting depth
25 mm
No-load speed
13,000/min
Weight
3.8 kg
Specifications
Input power
1,200 W
Cutting width
80 mm
Cutting depth
0-3 mm
Rabbeting depth
22 mm
No-load speed
13,100/min
Weight
6 kg
Planers
| Large planer
| Hand planer
Planer stand. To be fixed to a
workbench for using the planer in
a stationary position.
Planer stand. To be fixed to a
workbench for using the planer in
a stationary position.
