13
CE223X
+
Planers
| DUO planer
The DUO planer is a total new con-
cept.Equippedwithinterchangeable
tool holders for helicoidal blade and
sanding roller.
Easy to adapt to the wanted finis-
hing, just changing the tool holder
with helicoidal blade or sanding
roller in few minutes.
The tool holder with helicoidal bla-
de provides a high quality planing
without traces and less noise, thanks
to the oblique cutting.
The abrasive roller can be used for
sanding several kind of materials:
wood and its products, solid sur-
face materials, synthetic materials,
stripping paints on flat surfaces...
Adjustable rear shoe regarding the
cutting line of the tool holder.
Standard equipment
Tool holder with helicoidal blade,
tool holder for abrasive roller with
abrasive roller Gr. 40, lateral fence,
carrying case and dust collection
nozzle.
Its versatility makes it to be able to
adapt to several kind of jobs just
onlychangingthetoolholder.With
the sanding roller, it is possible to
plane doors or shelves without risk
to splinter them.
Optional accessories
2346558 Tool holder for straight
reversible blades.
6446073 Dust collector attach-
ment 2.25 m.
1746245 Dust collector attach-
ment 5 m.
There are several applications using
the sanding roller.
For example: sanding wooden
repairing splines, planing panels
made up with several layers of
different materials, like insulating
modules, repairing of surfboards,
boats...
Specifications
Input power
700 W
Cutting width
80 mm
Cutting depth
0-3 mm
Max. rabbeting depth
11 mm
No-load speed
16,500/min
Max. sanding depth
0 - 1 mm
Sanding roller width
81 mm
Weight
3.2 kg
The CE223X DUO can be adapted to several kind of
surfaces thanks to its dual system.
Optional sanding rollers
2345510 Roller g. 40 Carborundum
2345511 Roller g. 50 Carborundum
2345512 Roller g. 60 Carborundum
2345514 Roller g. 60 (Zirconium Oxide)*
(*) for hard materials
