9
FR98H
Designed for shaping the edges of
longitudinal beams and crossbeams
andmodeling coffered ceilings. Fac-
tory fitted with two different sets
of blades, with their correspondant
cutter-holders, for moulding and
bevel edging. Using the optional
blades, with different radius and
profiles it is possible to obtain a
great variety of different finishings.
Thewidthof the straight ormoulded
profile obtained can be set between
0 and 40 mm. The guide on which
the piece to be shaped rests can be
moved with respect to the blades,
which means that different profiles
can be made on an edge, according
to the zone of the blade on which
work is being done. There are two
handles, one parallel to the main
grip and at the same level, allowing
a comfortable work on longitudinal
beams and vertical parts, and a top
knobwith twooptional positions for
work on horizontal surfaces, thus
in both cases allowing a perfectly
comfortableandsecuretwo-handed
griponthemachine.Machineequip-
ped with a smooth electronic star-
ting system and safety connection
cut-off switch to avoid undersired
start-up. It is also equipped with a
dust collection nozzle.
Specifications
Input power
1,300 W
Maximum cutting width
40/20 mm
No-load speed
23,000/min
Max. blades pitch diameter
49 mm
Weight
4.9 kg
Optional accessories
9800150 Radius copier. Allows straight chamfered
edges to be made on pieces with exterior circular
curves
6446073 Standard dust collector connection 2.25 m
1746245 Standard dust collector attachment 5 m
Safe and comfortable handling.
Radiuscopier(optional).Edgeroun-
ding or cutting on radius (R=5, 10
or 15) is also possible using radius
blades 9841005.
Blades and cutter-holders (included with standard equipment)
Ref.
Description
9841004 Set of two carbide straight blades
9845239 Cutter-holder for straight blades
9841006 Set of two carbide moulding blades
9845273 Cutter-holder for moulding blades
Ref.
Description
9841005 Set of two carbide blades for 1/4 R=5, 10 & 15
9845270 Cutter-holder 1/4 R=5, 10 & 15
9841010 Set of two carbide blades for 1/4 R=25
9845271 Cutter-holder 1/4 R=25
9841011 Set of two carbide blades for 1/2 R=4,5 & 7
9845272 Cutter-holder 1/2 R=4,5 & 7
Blades and cutter-holders (optionals)
Ref.
Description
9841012 Set of two carbide blades R=25
9845332 Cutter-holder R=25
9841013 Set of two carbide blades R=20/90°
9845333 Cutter-holder R=20/90°
9841014 Set of two carbide blades R=10 and 10
9845334 Cutter-holder R=10 and 10
9841015 Set of two carbide blades R=5, 20 and 5 180°
9845335 Cutter-holders R=5, 20 and 5 180°
9841016 Set of two carbide blades R=-20
9845336 Cutter-holder R=-20
9841017 Set of two carbide blades R=-7,7,7 y-7
9845337 Cutter-holder R=-7,7,7 and-7
Base with guide extension Ref.
9800050 (Optional).
Planers
| Shape planer
Types of profiles
Blades and cutter-holders (optionals)
