24
A
B
C
FR192N
Excellent finishingwhen trimming
laminates.
Trimming rabbet with optional bit
1240046 (and sliding shoes ref.
1250041 or 1850042)
Making mouldings.
Equipped with electronic speed
control and electronic system
whichmaintainsthespeedconstant
independently to theworking load.
Trimming parallel slots.
Trimmers
Light weight designed for several
kind of jobs. Provides excellent
finishing on laminate trimming.
Possibility to make right or circular
slots in an easy and precisewaywith
the accessories included as standard
equipment.
Optional accessories
1222024 Chuck collet 8 mm
1222085 Chuck collet 6.35 mm (1/4”)
1240046 Rabbeting bit
Templates for fitting hinges
(see page 62)
Clamping systems (see page 89)
Guide rings
1250001 Ø ext. 10 mm
for 6 mm bits
1250002 Ø ext. 12 mm
for 8 mm bits
1250003 Ø ext. 14 mm
for 10 mm bits
1250004 Ø ext. 16 mm
for 12 mm bits
1250025 Ø ext. 18 mm
for 14 mm bits
1250035 Ø ext. 20 mm
for 16 mm bits
Specifications
Input power
750 W
Max. bit diameter
25 mm
Chuck collet
6 mm
No-load speed
14,000-30,000/min
Weight
1.8 kg
C
B
A
45° sliding shoe
Ref.1850042
Flat sliding shoe
Ref.1250041
Sliding shoe
Ref. 1250040
Flat sliding shoe
25 mm
Ref. 1250078
| Electronic trimmer
Trimming circular slots.
Optional
accessories
Standard equipment
Carbide flush/bevel bit, lateral
fence with compass, guide ring and
service keys.
Bits
see pag. 48
Optional
Trimming head for fitting hinges
ZB93 (ref. 1750000).
