31
FR160P
FRE160P
Routers
| Router
Professional routers for wood and
plasticmaterials.Highprecissionand
stability when routing. Fast depth
adjustment with 6 pre-adjusted
postions. Their powerful motors
(FR160: 1,500 W. FRE160P: 1,800 W)
make them suitable for hard, conti-
nuous jobs. Ideal for trimming edges,
cutting knots, copy milling, dovetail
assemblies (with the optional PL11
dovetailing attachment), making re-
cesses for carpentry hardware, etc...
Equippedwithfineadjustmentofthe
routing depth and a lateral fence
(delivered as standard equipment).
Blocking system of the motor shaft
for an easy change of bit. External
dust collector connection for a clean
and safe working area.
Specifications
Input power FR160P/FRE160P
1,500 W/1,800 W
Chuck collet
12 mm
Routing depth
0-60 mm
No-load speed FR160P
25,000/min
No-load speed FRE160P
11,500-23,000/min
Max. bit diameter
40 mm
Weight
5.4 kg
Supplied with lateral fence with
micrometric adjustment and
adjustable rules.
Micrometric adjustment of routing
depth. 6 adjustable depth postions
for rapid selection of the desired
depth.
Total locking system for the routing
depth,idealfordovetailingandother
jobs requiring total locking of the
machine head.
Model FRE160P equipped with
electronic speed control and elec-
tronic system which maintains the
speed constant independently to
the working load.
Guide rings
(models FR160P and FRE160P)
7722168 Ext. Ø 10 mm (for 6 mm bits)
7722120 Ext. Ø 12 mm (for 8 mm bits)
7722121 Ext. Ø 14 mm (for 10 mm bits)
7722122 Ext. Ø 16 mm (for 12 mm bits)
7722169 Ext. Ø 18 mm (for 14 mm bits)
7722118 Ext. Ø 20 mm (for 16 mm bits)
7722119 Ext. Ø 27 mm (for 23 mm bits)
7722114 Ext. Ø 30 mm (for 26 mm bits)
7722161 Guide for PL11 width 16 mm
7722123 Guide for PL11 width 26 mm
7722162 Guide for PL11 width 34 mm
7722160 Guide for AGB template Ø 27 mm
7722342 Guide for AGB template Ø 21 mm
Standard equipment
Lateral fence, dust collector
connection, guide ring Ø 19 mm
for dovetailing pitch plate 26 mm
and service key, reducer 8 mm and
reducer 6 mm.
Optional accessories
(models FR160P and FRE160P)
6045669 Compass guide
6045715 UC60 Universal compass
guide
66446073 Standard dust collector
attachment 2.25 m
1746245 Standard dust collector
attachment 5 m
6040313 Bit for AGB template for
bottom-hung fittings
Templates for fitting hinges
(see page 62)
9045705 UC90P Cutting guide
Clamping systems (see page 89)
Double fence
6045665 (optional)
| Electronic router
Bits
see pag. 48
FRE160P FRE160P
