30
FR66P
Routers
Specifications
Input power
1,300 W
Chuck collet
8 mm
Routing depth
0-60 mm
No-load speed
26,000/min
Max. bit diameter
30 mm
Weight
3.8 kg
Router for wood and plastic ma-
terials. High precision and stability
when routing. Full control of the
machine without releasing the
handle.Rapiddepthadjustmentwith
three positions. Its powerful 1,300
W motor makes it specially suitable
for hard, continuous jobs. Ideal for
roughfacing edges, cutting knots,
copy milling, dovetail assemblies
(PL11 dovetailing attachment), ma-
kingrecessesforcarpentryhardware,
etc... Equipped with external dust
collection connector.
Optional accessories
6045669 Compass guide
6045715 UC60 Universal compass
guide (see pag. 37)
6027020 Chuck collet 6 mm
6727020 Chuck collet 6.35 mm (1/4”)
6446073 Standard dust collector
attachment 2.25 m
1746245 Standard dust collector
attachment 5 m
6640125 Bit for AGB template for
bottom-hung fittings
Templates for fitting hinges
(see page 62)
9045705 UC90P Cutting guide
Clamping systems (see page 89)
Total locking systemfor the routing
depth, ideal for dovetailing assem-
blies andother jobswhich requiring
total locking of the headpiece.
On-Off switch and head blocking
may be activated from the knob,
giving total, safe control of the
machine.
Standard equipment
Lateral fence, dust collector
connection, guide ring Ø 19 mm
for dovetailing pitch plate 26
mm and service key.
Six adjustable depth positions
for rapid selection of the desired
routing depth.
Guide rings
7722168 Ext. Ø 10 mm (for 6 mm bits)
7722120 Ext. Ø 12 mm (for 8 mm bits)
7722121 Ext. Ø 14 mm (for 10 mm bits)
7722122 Ext. Ø 16 mm (for 12 mm bits)
7722169 Ext. Ø 18 mm (for 14 mm bits)
7722118 Ext. Ø 20 mm (for 16 mm bits)
7722119 Ext. Ø 27 mm (for 23 mm bits)
7722114 Ext. Ø 30 mm (for 26 mm bits)
7722161 Guide for PL11 width 16 mm
7722123 Guide for PL11 width 26 mm
7722162 Guide for PL11 width 34 mm
7722160 Guide for AGB template Ø 27 mm
7722342 Guide for AGB template Ø 21 mm
Supplied with lateral fence with
micrometric adjustment and ad-
justable rules.
| Router
Double fence
6045665 (optional)
Bits
see pag. 48
