| Template for stairs
| Routing templates
Template designed specially for
routing open stairs or with riser
Provides a quick and easy routing of
the recesses on the stringerswithout
to draw all the dimensions.
Reversible, for right and left
stringers.
Ensures a high precision of routing
simplifying the assembly of the
treads.
Tread thickness adjustable from 18 to 55
mm with the standard templates.
Routingwithbit Ø15mmcollet Ø12 (code
6040379 optional) and guide ring Ø 27
mm (code 7722119 delivered as standar).
r = 7,5 mm
Standard noising tread
Optional accessories
6046578 Extension set for stair
landings from 600 mm to 1000 mm
3345634 Anglecopy TC133R
Quick and easy routing of the
recesses on the stringers
On demand, different kind of
special nosing tread templates
(ref. 6033167).
Equipped with a special stopper for
a 90º trimming.
Routers · Accessories for routers
Routing templates PF400 and PF700
allow complex trimmings with the
aid of a router. Among the various
working possibilities they offer,
include lace and routing grooves,
routing perimeter edges or frames
or routing arcs and circles.
Max. working area with PF400:
120x320 mm
Max. working area with PF700:
320x620 mm
The routing process is performed
with high stability and efficacy.
The optional base adapter ref.
6046478 is especially useful in
those works necessary to work
the inside of a large workspace
The use of PF400 and PF700 tem-
plates allowsmultiple applications.
Optional accessories
6046519 Extension set PF200
6046520 Extension set PF400
6046521 Extension se PF700
6045710 Set of 2 clamp screws
Optional guide rings
7722118 Guide ring for bits Ø max. 13 mm
7722162 Guide ring for bits Ø max. 16 mm
7722119 Guide ring for bits Ø max. 20 mm
7722114 Guide ring for bits Ø max. 23 mm
