33
Routing head included as stan-
dard equipment
Routing head equipped with mi-
crometric depth adjustment with 6
depth stoppers.
Lateral fence equipped also with
micrometric adjustment.
With dust collection nozzle.
Trimming head with large support
for straight or shapped panels.
Brake for the bit bearing, avoi-
ding that it can damage the panel
when starting to work.
Optional (5600060).
Round head for trimming on
edge. Brake for the bit bearing,
avoiding that it can damage the
panel when starting to work.
Optional (5646365).
Without any head can be
used as a straight grinder.
The COMBI router can be
used with several heads:
Trimming heads 5600060 and
5646365 are equipped with dust
collection nozzle.
It can work as a router, can be transformed
into a trimmer and also as a straight grinder
For finishing and sanding metals.
(Grinding tool not included).
Specifications
Input power
1,000 W
No-load speed
14,000-27,000/min
-1
Chuck collet
8 mm
Weight
3.8 kg
Optional accessories (use as a trimmer)
1222084 Chuck collet 6 mm
1222085 Chuck collet 6.35 mm (1/4”)
6446073 Standard dust collector attachment 2.25 m
1140123 HM bit r=2 mm with bearing
1140106 HM bit r=3 mm with bearing
1140109 HM bit r=6 mm with bearing
1140110 HM bit r=8 mm with bearing
6399082 Cantspray
Optional accessory (5646343):
Preciseguidingforcornertrimming.
