RM95S
Installation and restoration of doors and windows
| Door frame cutting machine
The definitive solution for changing
doors on restoration works, keeping the
original door dimensions.
Adjustable cutting up to 155 mm width.
It is also possible to cut the crossbeam.
The powerful 1800 W motor, soft star-
ting and chain saw give an easy and
fast cutting.
Quick assembly and adjustment.
Pinion rack system, for a smooth mo-
vement and cut with no-return system
for a safety operation.
Dust collector connection and cord 5
m long.
Standard equipment
Cutting machine with
chain saw
Metal detector
Carrying case for the machine
Carrying bag for the guides
Lubricating oil (125 ml)
Equipped with an effective chain
saw for a clean and easy cut. Fitted
withsafetyprotectionstoavoidany
contact with the chain saw, even
during the cut.
Solid and efficient pinion rack
system for a total control of cut.
Practice system to fix the machine
to the frame and to adjust the
cutting width.
Clean cut allowing to fix
the new frame directly on
the old ones.
Specifications
Input power
1,800 W
Chain saw speed
15 m/s
Max. cutting depth
155 mm
Chain saw
3/8" 41 links
Weight
20.5 kg
Optional accessories
7000910 RV170U set for cutting frames up to 68 mm width
9500150 AC95R accessory for cutting crossbeams
9599263 Lubricating oil for RM95R (1 litre)
Only for special purposes when the standard guide is too high.
9545751 Upper guide max. height 194 cm
9545752 Upper guide max. height 206 cm
Patented model
