78
0° - 0°
150
80
0° - 45°
103
45°
80
45° - 0°
150
45°
65
45° - 45°
45°
45°
63
60
TS72C
TM72C
Specifications
Input power
1,200/1,300 W (depending on version)
No-load speed
3,000/min
Saw blade diameter
300 mm
Weight
30 kg
Mitre saws
High precision powerful tiltablemi-
tre saw. Cutting capacity up to 150
mm. Head can be tilted from 0° to
45°. Equippedwithadjustableupper
table including adjustable square.
Integral safety system with saw
blade brake and protection against
intempestive switch on. Connector
for external dust collection. Power-
ful, precise and safe.
High precision: the machine is
designed for high precision in any
position.
Optional accessories
7500092 Pressers set
6446073 Standard dust collector
attach. 2.25 m (for working on
upper table)
5800100 MT58K Portable table
Standard equipment
Professional carbide saw blade Ø
300 mm 48 Z, length cutting gui-
de, square guide and service keys.
Mitre saw similar to model TM72C, but
without upper table.
The machine can be connected to
the external dust collector.
Optional: Pressers set (code
7500092).
The TM variations include an upper
table for auxiliary works.
Protectionagainstaccidentallowe-
ring of the head. Total protection
against mains cut off.
Head can be tilted from 0° to 45°.
The machine head can be turned
from 0° to 45°.
Electrical versions
TM72C: 220V, 1200W, Single pha-
se, with upper table
TS72C: 220V, 1200W, Single phase,
without upper table
TM73C: 220/380V, 1300W, 3-pha-
se, with upper table
TS73C: 220/380V, 1300W, 3-phase,
without upper table
Cutting capacity
| Mitre saw
Cutting capacity
Head
Table
Capacity
0°
to 0°
80x150 mm
to 45°
80x103 mm
45°
to 0°
65x150 mm
to 45° left
63x60 mm
Max. cutting capacity on upper table: 35 mm.
Upper table dimensions: 340x417 mm
Saw blades
see page 81
Wood
