77
TS48L
0° - 0°
145
62
0° - 45°
95
45°
62
45° - 0°
145
45°
45
45° - 45°
45°
45°
43
45
TM43L
Tiltable mitre saw. Highly versatile
performing mitres, bevels and
combinationmitre cuts. With upper
table and dust collector connection.
Integrated safety system with saw
blade brake and protection against
intempestive switch on.
Base is one block giving a large
supporting area. A new table with
nongrip turning system.
Optional accessories
3345416 Pressers set
3345470 Set of lateral handles
7246098 Square for table (pag. 76)
6446073 Standard dust collector
attach. 2.25 m (for working on
upper table)
5800100 MT58K Portable table
Standard equipment
Professional carbide saw blade
Ø 250 mm 40 Z, length cutting
guide and service keys.
Tiltable mitre saw similar to TM43L model
but without upper table.
Equipped with a safety mechanism
against accidental lowering of the
cutting head.
Mitre saws
Specifications
Input power
1,100 W
No-load speed
5,500/min
Saw blade diameter
250 mm
Weight
18 kg
Optional: Set of lateral handles for
easy carrying on (code 3345470).
Upper table with guide and riving
knife. Ideal for piece work and
adjustments. Total protection from
the blade.
The height of the handle can be
adjusted for greater comfort.
Optional: Pressers set (code
3345416).
Cutting capacity
Head
Table
Capacity
0°
to 0°
62x145 mm
to 45°
62x95 mm
45°
to 0°
45x145 mm
to 45° left
43x45 mm
Cutting capacity
| Mitre saw
Saw blades
see page 81
Wood
Max. cutting capacity on upper table: 40 mm
Upper table dimensions: 307x375 mm
