88
A
EM25D/EM26D
EM125T/EM126T
Model
EM25D / EM26D EM125T / EM126T
Rubber roller
2504005* - 122 mm 2504279* - 180 mm
Polyurethane roller
2504065 - 122 mm 2504280* - 180 mm
Hand gluers
Hand gluer for gluing large surfaces
using vinyl glue (white glue). Equip-
ped with trigger shut-off device to
stop the flow of glue. Also comes
with a support where it can be left
when not in use, thus keeping the
workingarea andthemachineclean.
Gluing roller width: 122 mm.
The model EM25D is equipped with
an auxiliary upper roller for clean
gluing strips.
Gluing with vinyl (white) glues
Gluing with the upper roller.
Specifications
Lower roller width
EM25D-EM26D/EM125T-EM126T
122 mm/180 mm
Upper roller width
92 mm
Tank capacity EM25D-EM26D/EM125T-EM126T
1 kg/1.4 kg
| Hand gluer
| Hand gluer
Optional accessories
A range of hand gluers for gluing
large surfaces using vinyl or synthe-
tic glues (white glues). Equipped
with trigger shut-off device to stop
the flow of glue. Also come with a
supportwhere they canbe leftwhen
not in use, thus keeping theworking
area and the machine clean.
Gluing roller width: 180 mm.
The model EM125T is equipped with
an auxiliary upper roller for clean
gluing strips.
All models are quipped
with trigger shut-off
device to stop the flow
of glue.
Rubber roller:
for white glues and water-soluble emulsions. Amount
of glue to be applied: MEDIUM.
Polyurethane roller:
for synthetic resin glues, white glues, and water-
soluble emulsions. Amount of glue to be applied: LITTLE.
* Included as standard equipment
Gluing with vinyl (white) glues
Gluing with the upper roller.
A
