PR25P
Low maintenance, hot melt edge
pre-gluer for pre-gluing materials
such as: plastic or wood laminate
strips, layered strips, 0.4 to 2 mm
PVCedges, ABS, polyester,melamine
or wood veneer tapes.
The machine glues tapes for later
use with edfebanders for pre-glued
tapes, as manufactured by Virutex,
or with any hot air edgebanding
machines.
It has thermoelectric temeprature
control, automatic start and stop of
the feed motor, depending on the
glue tmeprature, and an accurate
dosage mechanismwhich dispenses
the exact amount of glue to obtain
the required density on the back of
the tape. It consumes between 160
and 200 g of glue per sqm. It has a
built-in manual winder which lets
the original roll easily unwind and
then rewinds itwith the tape already
glued and ready for use. Using the
optional kit, two similar tape rolls
can be pre-glued at the same time.
Pre-gluer for tapes
| Pre-gluer for tapes
Specifications
Input power
1,720 W
Minimum tape thickness
0.4 mm
Max. tape thickness (strip)
16 mm
Max. tape thickness (roll)
2 mm
Maximum tape width
104 mm
Feeding speed
510 m/h=8.5 m/min
Tank capacity
2 Kg of glue
Weight
26 kg
Easy to handle and start, allows
rolls to be preglued without com-
plications.
High quality pre-gluing.
Pre-gluing strips.
Standard equipment
Manualwinder,2multidiameterreel
centering devices, 1 kg of glue and
a cardboard roll centre ring.
2545631Doublewinder for the
manual PR25P. Simultaneously
pre-glues two edge rolls with
the same thickness (contains:
4 reel loading discs, 8 reel
centring devices, assembly and
instruction manual).
Optional accessories
2545628 DV25P Automatic
winder. Kit to convert the ma-
nual PR25P into an automatic
PR25P-DV.
A
A
2502522 Multi-diameter reel centring device (2
units included with standard equipment)
2545659 Pack of 25 Ø 85-mm cardboard rings
for edge roll centres
2545660 Pack of 25 Ø 150-mm cardboard rings
for edge roll centres
2599242 Hot melt glue, 1 kg bag
